THE E-ONE

TITAN 4×4 AT

AIRCRAFT RESCUE FIRE FIGHTING (ARFF)

The E-ONE TITAN  4×4 AT (Air Transportable) Series is designed as an aircraft rescue firefighting vehicle that allows transport on C5, C17, and C130 aircraft. On and off-road capabilities allow the vehicle to respond in a timely manner to aircraft accident sites across terrain which might otherwise be inaccessible to other standard fire apparatus. The vehicle is designed for maximum stability and maneuverability under all operating conditions. With a full compliment of water, foam and dry chemical onboard, the TITAN 4×4 AT can reach a maximum speed of over 70 mph and exceeds all industry standards for dynamic stability, as well as structural and pump and roll performance capabilities. This unique apparatus offers an air ride suspension for operator comfort no matter the terrain, that also allows the vehicle’s stance to be lowered for transport. The quick connect/storage functionality of its exterior components lets the vehicle transform in just minutes for rapid deployment when called upon.

Features

  • Certified for Air Transportability on C5, C17 and C130 aircraft models
  • Extruded aluminum roll-cage cab design featuring seating for up to four (4) personal with ergonomic layout of all firefighting and operational functions
  • Air ride suspension with kneel feature
  • Disc brakes on the front and rear axles offer unsurpassed performance exceeding Federal Motor Vehicle Safety Standards (FMVSS 121)
  • Unsurpassed equipment storage with four (4) compartments located on each side to provide over 150
    cu. ft. of usable storage capacity
  • 1000 gal. (3,785 liter) polypropylene water tank and 140 gal. (529 liters) polypropylene foam tank featuring a lifetime warranty
  • Darley PSP single stage pump rated up to 1,500 GPM (5,678 LPM)
  • Dry chemical system up to 250 lbs. (113 kgs.)
  • Bumper and roof turret options available with flow rates of 375 GPM (1419 LPM) low flow / 750 GPM (2839 LPM) high flow
  • Akrochem turret nozzles for greater reach and penetration
  • Hose reel and pre-connected hand line configurations
  • Patented ECOLOGIC integrated foam testing system for accurate testing of foam percentages
  • Winterization system for -40 F˚/C˚ extreme climates
  • Auxiliary diesel generator up to 5KW @ 110 volts
  • Thermal imaging camera packages for limited visibility conditions
  • Scene / quartz lighting options for night operations
  • Ladder and hand tool storage configurations
  • Davit crane available for lowering removable options to ground level
