THE E-ONE

HP 100 PLATFORM

AERIAL PLATFORMS

ROCK SOLID PERFORMANCE

The HP 100 Platform is a powerhouse of an aerial. It has the muscle to hoist 1,000 lbs. of firefighters and 305 lbs. of equipment 100 feet in the air without sacrificing safety thanks to a 2.5 to 1 structural safety factor.

The innovative E-ONE HP 100 Platform is a three-section aluminum aerial providing a 100’ vertical reach and 91’6” horizontal reach while offering a 2.5 to 1 structural safety factor – exceeding the minimum NFPA requirements of 2 to 1. A standard single monitor or optional dual monitors with up to 2000 GPM flow, combined with up to 182’ of enclosed group ladder storage makes the E-ONE 100 Platform an invaluable resource at a fire scene.

Features

  • Typhoon® or Cyclone® II chassis
  • Medium, long and extended length 4-door cabs available
  • Optional split-raised roof
  • Integral torque box chassis
  • 250”-260” wheelbase
  • 500-600 HP engine
  • Standard safety features such as roll cage cab, CrewGuard, ABS brakes & G4 (electronic stability control)
  • Optional air bags
  • 100’ welded extruded aluminum platform with 2.5 to 1 structural safety factor
  • Platform rated at 1,305 lb dry (1000 lbs firefighters & 305 lbs equipment); 805 lb wet (500 lbs firefighters & 305 equipment)
  • Criss-cross underslung jack spread of only 15’6”
  • Angled platform corners with perimeter step
  • Body protection and variable speed control standard
  • 11’10” overall height
  • 2” lower overall height available with Cyclone II aerial cab
  • Aerial information system(AIS) standard
  • Options include single or dual monitors, 2.5” valves, hoseboxes, breathing air, parapet ladder, tie-off package, stokes receiver, LED or halogen scene lighting
  • Body available in extruded aluminum
  • Available with SideStacker body or “truck company” style with no tank or pump
  • Rear side stair case for easy turn table access
  • Up to 182’ of ground ladder storage with tank and pump, meeting ISO requirements
  • Hale® or Waterous® pumps up to 2000 GPM
  • Optional foam systems; direct injection, and around the pump (ATP)
  • 300-500 gallon water tank
  • Customizable discharges and pre-connects to meet departments needs
  • Stainless steel discharge manifold
  • Multiplex electrical system with color display provides increased feature capability and improved diagnostics
  • Options include LED scene lights, LED ladder climbing lights and 6-20  kW hydraulic generators
  • Whelen® optical and audible warning packages standard, others optional

WHY 2.5 to 1 MATTERS

WHY ACCEPT 2 TO 1 SAFETY FACTOR

Engineered with a 2.5 to 1 structural safety factor versus the NFPA minimum of 2 to 1, results in a complete aerial design from the ground up that stands stronger, 25% stronger.

THE STRONGEST CAB IN THE INDUSTRY

EXCEEDS NFPA REQUIREMENTS

Keep your crew safe with the cab that withstands over five times the static roof load an over twice the frontal impact required by the NFPA.

HP 100 PLATFORM HIGHLIGHTS
