HP 100 Platform
City of Virginia Beach Fire Department

HP 100 Platform
City of Virginia Beach Fire Department

CUSTOMER INFORMATION

Truck Type: Aerials
Location: City of Virginia Beach Fire Department
Dealer Name: Blue Ridge Rescue Suppliers
Shop Order: 140777
Pump: Aerials

More Information

  • Cyclone long cab with 260” wheelbase
  • Cummins ISX12 500 HP engine with Allison EVS4000 transmission
  • Integral torque box chassis
  • Heavy duty extended front bumper with two hydraulic reels and rescue tools
  • 9,000 lb underbody receivers located two each side
  • 4-Front and RollTek air bag systems
  • 100’ extruded aluminum platform with 1305 lb. tip load and 2.5 to 1 structural safety factor
  • Crisscross under-slung jacks with a spread of 15’ 6”
  • Laser jack pad spotting lights
  • Dual Akron StreamMasterII electric monitors on platform
  • Extruded aluminum body with SideStacker hosebed
  • Wheelwell storage compartments for SCBA bottles and wheel chocks
  • Waterous CSU single stage pump rated at 1500 GPM
  • 300 gallon water tank
  • Safety Vision back-up camera wired through multiplex display
  • Whelen upper and lower level warning lights
  • Harrison 8kW hydraulic generator with two cord reels
